Marine Fluorescent Pendant Light – JCY-22
The scope
Fit for Illumination of water dripping, water spattering, water coagulating place in ships, such as oven cabin, dry cabin, tunnel,
pipeline and weather deck etc.
Products characteristic
-
- The shell adopts good quality steel plate tensioned, lampshade adopts injection of PC and has the seal structure.
- ln order to prevent from electric shocking, equipped with a copper earthing rod with the mark ground connection in and out the lights.
- Plug-in type lamp holder, equipped wiring terminal inside, convenient to connect.
- The lamp equipped B15 lamp holder, used for 24V/15W emergency bulb, the edge of lampshade marks the RED marking. remark clear that need the emergency device when order.
- Equipped compensating capacitance inside the lamp, also has a good effect of start.
Adopt standard
Conform to IEC60092-306-209 standard and GRADE ENTRY NORMS FOR STEEL SHIPS.
Specification
|
IMPA CODE |
Type | Power | Voltage | Power factor | Lamp Holder | Cable Outside Diameter | Protection Class | Weight | Remark |
| 791882/791513 | JCY22-2 | 2x20W | 110V/60HZ 220V/50HZ 220V/60HZ |
>0.85 | G13 | Φ14-Φ16 | IP56 | 5.2kg | —— |
| JCY22-2E | 5.3kg | With Emergency | |||||||
| 791862/791909
791872/791911 |
JCY22-2EF | 6.9kg | With Emeraencvand Mesh Cover | ||||||
| JCY32-2 | 2x30W | 110V/60HZ
220V/50HZ 220V/60HZ |
>0.85 | G13 | Φ14-Φ16 | IP56 | 9.1kg | — | |
| JCY32-2E | 9.2kg | With Emergency | |||||||
| JCY32-2EF | 10.0kg | With Emergency and Mesh Cover | |||||||
| 791804/7S1087 | JCY42-2 | 2x40W | 110V/60HZ 220V/50HZ 220V/60HZ |
>0.85 | G13 | Φ14-Φ16 | IP56 | 9.3kg | — |
| JCY42-2E | 9.4kg | With Emergency | |||||||
| 791864/791867
791874/781B77 |
JCY42-2EF | 10.2kg | With Ememencyand Mesh Cover |
Marine Fluorescent Pendant Light – JCY-22
