The scope of application

WB series

This series lights fit for the ships with water dripping, water spattering and weather place, such as oven cabin room, dry cabin, tunnel, pipeline and weatherdeck etc, wall-type installation.

CBD1 series

Used for auxiliary illumination in ship cabin.

Specification
IMPA
CODE 		type Power Voltage Material Lamp holder Color protection class Weight
792067 WB-1 15W 24V Synthetic resin FE12、FE14
FB15		 transparent
red
green
yellow
blue		 IP56 0.83kg
792068 WB-2 60W 220V FE26、FB22 IP56 1.26kg
WB-2A 60W 220V Aluminum FE26 IP56 1.45kg
792068 WB-2B 60W 220V Synthetic resin FE26 IP56 1.26kg
CBD1 25-60W 220V/24V Steel red 0.95kg
